Club Car®
Carryall 700 Electric IQ Utility Vehicle

What’s the most important part of your golf swing? It’s Tempo of course.

The Club Car Tempo™ ‘Fleet Edition’ golf car has been designed from the ground up with the serious golfer in mind. The Club Car Tempo™ ‘Fleet Edition’ brings together safety, reliability and style into a package that will no-doubt compliment your game.

Carryall 700 Electric IQ Utility Vehicle

Features:

  • Battery Capacity Indicator
  • On-Board Delta-Q™ Battery Charger
  • Heavy-Duty Front Brush Guard
  • 6 Ply Premium Tread Tyres
  • Heavy-Duty Suspension
  • LED Head Lights (wired through ignition)
  • Tail / Brake Lights
  • Horn
  • Directional Indicators
  • 12-Volt In-Dash Power Outlet
  • 4-Wheel Brakes
  • Reverse Warning Buzzer
  • Radio / Beverage Holders
  • 25 Amp DC Converter (48-12 Volt)
  • Hour Meter
  • Differential Guard
  • Tow Bar & Ball
  • Aluminium Flat-Bed Tray with Bed Lift (454kg Load Capacity)
  • Battery Capacity Indicator
  • On-Board Delta-Q™ Battery Charger
  • Heavy-Duty Front Brush Guard
  • 6 Ply Premium Tread Tyres
  • Heavy-Duty Suspension
  • LED Head Lights (wired through ignition)
  • Tail / Brake Lights
  • Horn
  • Directional Indicators
  • 12-Volt In-Dash Power Outlet
  • 4-Wheel Brakes
  • Reverse Warning Buzzer
  • Radio / Beverage Holders
  • 25 Amp DC Converter (48-12 Volt)
  • Hour Meter
  • Differential Guard
  • Tow Bar & Ball
  • Aluminium Flat-Bed Tray with Bed Lift (454kg Load Capacity)
Carryall 700 Electric IQ Utility Vehicle

Club Car® Carryall 700 Electric IQ Utility Vehicle

SPECIFICATION:

MOTOR 48-Volt DC
CONTROLLER 500 Amp - Solid State
HORSEPOWER 3.7 hp (2.7 kW) rated, Peak 20 hp (14.9 kW)
MAX TORQUE 71 ft-lbs (96.2 N-m) rated @ 1450 rpm
TRANSMISSION Direct drive, double reduction helical gear
GEAR SELECTION Forward/Neutral/Reverse
GEAR RATIO 12.32:1
BATTERY Eight (8) - 6 V Flooded Lead Acid
CHARGER DeltaQ QuiQ (1 kW High Frequency)
HEADLIGHTS Two 37.5-Watt Halogen
STEERING Self-adjusting Rack and Pinion
SUSPENSION (FRONT) Independent leaf spring with dual hydraulic shocks
SUSPENSION (REAR) Semi-Independent leaf spring with dual hydraulic shocks
BRAKES 4-Wheel Mechanical Drum
PARK BRAKE Foot Operated, Multi-lock
TIRES (FRONT) 20 x 10-10, 6-ply
TIRES (REAR) 20 x 10-10, 6-ply
BODY (FRONT & FINISH) ArmorFlex with Automotive Paint/Clearcoat
BODY (REAR) Aluminium
WHEELBASE 251.7 cm
OVERALL HEIGHT 119.6 cm
OVERALL LENGTH 349.3 cm
MAX WIDTH (W/O MIRRORS) 127.7 cm
GROUND CLEARANCE 14.2 cm
TRACK WIDTH (FRONT) 92.9 cm
TRACK WIDTH (REAR) 100.3 cm
CARGO BED LxWxH 163.8 x 120.6 x 26.6 cm
VEHICLE CURB WEIGHT 669 kg
BED LOAD CAPACITY 453.5 kg
TOTAL VEHICLE CAPACITY 680.3 kg
TOWING CAPACITY 680.3 kg
COMBINATION RATED CAPACITY 680.3 kg
SPEED 8-27 kph
WARRANTY - BATTERY 4-year limited battery warranty
WARRANTY - POWERTRAIN 3-year limited powertrain and frame warranty
WARRANTY - VEHICLE 2 year limited remaining vehicle

* Vehicles specifications apply to the base model and may not reflect all selected options or accessories.

Nobody knows golf cars and utility vehicles like ADH Golf and Utility Vehicles. So please visit our showroom located at 42 Achievement Way, Wangara, Western Australia or contact us on (08) 6500 3756.
